Grevillea LED GR2 - LS192-2LED

A compact and versatile accent luminaire with two adjustable heads

Product Overview

The Grevillea is an excellent option for delivering light on the ground plane, or for feature accent lighting without obstruction from low-level plantings. Aim and tilt adjustability, a choice of finishes and long service life are all part of the package. The Grevillea also features the Lumascape d5 driver technology as a standard inclusion, providing a high level of control: When high output is required, it can be deployed in its full output, 6W configuration; If a lower level of light is required, it can be set as low as 0.6W, (either by the factory or in the field).

THIS LUMINAIRE IS ONLY AVAILABLE IN NORTH AMERICA

Features

Lumen Output 2 x 512lm Power Consumption 12W Control Protocol PWM (0-10V, DMX) IP Rating IP65 Compliance ETL - USA & Canada Color Options Warm White Cool White Blue (470 nm) Data Sheet

Specifications

Product Configurator

Customise Grevillea LED GR2 below

Light Engine

Required

12W (12)

Light Source

Required

Static White (D7)

Static White (D7)

2,700 K (80 CRI, 3 SDCM)

Static White (H6)

Static White (H6)

3,000 K (80 CRI, 3 SDCM)

Static White (W4)

Static White (W4)

4,000 K (80 CRI, 3 SDCM)

Single Color (B4)

Single Color (B4)

Blue (470 nm)

Beam Angles

Published angles may vary slightly to photometric data. Please refer to IES files where relevant.

Required

Narrow (NR)

Narrow (NR)

14°

Narrow Medium (NM)

Narrow Medium (NM)

25°

Medium (ME)

Medium (ME)

30°

Wide (WD)

Wide (WD)

40º

Input Voltage

Required

12-15 Vac, 60 Hz or 12-24 Vdc (23)

12-15 Vac, 60 Hz or 12-24 Vdc (23)

PWM Dimmable Driver

Finish

Required

Black (BL)

Black (BL)

Black powder coat

Anodic Silver (SL)

Anodic Silver (SL)

Anodic silver powder coat

Polished Copper (CU)

Polished Copper (CU)

Custom RAL (CC)

Custom RAL (CC)

A one-off custom colour setup fee applies. Click on 'More Info' button to add to your enquiry. Contact Lumascape for volume discount on set-up fee.

More info
