Portico LED PO1 - LS731LED

A compact and versatile wall grazer

Product Overview

The LS731LED Portico is a compact, fixed position, direct or indirect accent used for grazing walls or other accent illumination tasks. The luminaire is constructed from 316 marine grade stainless steel with Lumascape’s proprietary ElectroPolishPlus™ surface treatment, to provide a long life even in coastal environments. This luminaire is ideal for use in modern architectural designs, and features the Lumascape d5 driver technology for advanced dimming and control options.

THIS LUMINAIRE IS ONLY AVAILABLE IN NORTH AMERICA

Features

Lumen Output 220lm Power Consumption 3W Control Protocol PWM (0-10V, DMX) IP Rating IP65 Compliance ETL - USA & Canada Color Options Warm White Cool White Blue (470 nm) Data Sheet

Specifications

Product Configurator

Customise Portico LED PO1 below

Light Engine

Required

3 W (3)

Light Source

Required

Static White (D7)

Static White (D7)

2,700 K (80 CRI, 3 SDCM)

Static White (H6)

Static White (H6)

3,000 K (80 CRI, 3 SDCM)

Static White (W4)

Static White (W4)

4,000 K (80 CRI, 3 SDCM)

Single Color (B4)

Single Color (B4)

Blue (470 nm)

Beam Angles

Published angles may vary slightly to photometric data. Please refer to IES files where relevant.

Required

Narrow (NR)

Narrow (NR)

14°

Narrow Medium (NM)

Narrow Medium (NM)

25°

Medium (ME)

Medium (ME)

30°

Wide (WD)

Wide (WD)

40º

Input Voltage

Required

12 Vac, 60 Hz or 12 to 24 Vdc (13)

12 Vac, 60 Hz or 12 to 24 Vdc (13)

12-15 Vac, 60 Hz or 12-24 Vdc (23)

12-15 Vac, 60 Hz or 12-24 Vdc (23)

PWM Dimmable Driver

Finish

Required

316 Stainless Steel (SS)

316 Stainless Steel (SS)

Machined finished with ElectroPolishPlus™ surface treatment

Accessories

Power Supplies / Transformers

Power Supply 15V 20W (LSLED-15V20W277) (LSLED15V20W277)

Power Supply 15V 20W (LSLED-15V20W277) (LSLED15V20W277)

20W power supply with 15V DC output for non-dimmable applications
