Pagoda LED PA1

PA1
LS321LED
A compact and versatile wall grazer with an adjustable head
Configure this product

Product Overview

The LS321LED Pagoda is a compact, adjustable, direct or indirect accent used for grazing walls or other accent illumination tasks. The luminaire is constructed from either copper or powder-coated aluminium, providing a variety of aesthetic options. This luminaire is ideal for use in modern architectural designs, and features the Lumascape d5 driver technology for advanced dimming and control options.

THIS LUMINAIRE IS ONLY AVAILABLE IN NORTH AMERICA

Specifications

Features

Lumen Output 403lm Power Consumption 6W Control Protocol PWM (0-10V, DMX) IP Rating IP65 Compliance ETL - USA & Canada Colour Options BIM Blue Cool White Warm White Download Datasheet

Product Configurator

Customise Pagoda LED PA1 below

Light Engine

Required

6W (6)

6W (6)

Light Source

Required

3,000K, 80 CRI (H6)

3,000K, 80 CRI (H6)

Warm White (80 CRI, 3 SDCM)

4,000K, 80 CRI (W4)

4,000K, 80 CRI (W4)

Cool White (80 CRI, 3 SDCM)

470nm (B4)

470nm (B4)

Blue

Beam Angles

Published angles may vary slightly to photo-metric data. Please refer to IES files where relevant.

Required

Narrow (NR)

Narrow (NR)

14°

Narrow Medium (NM)

Narrow Medium (NM)

25°

Medium (ME)

Medium (ME)

30°

Wide (WD)

Wide (WD)

40º

Input Voltage

Required

12-15V, 60Hz or 12-24V DC (23)

12-15V, 60Hz or 12-24V DC (23)

PWM Dimmable Driver

Finish

Required

Black (BL)

Black (BL)

Black powder coat

Anodic Silver (SL)

Anodic Silver (SL)

Anodic silver powder coat

Polished Copper (CU)

Polished Copper (CU)

Accessories

Power Supplies / Transformers

Power Supply 15V 20W (LSLED-15V20W277) (LSLED15V20W277)

Power Supply 15V 20W (LSLED-15V20W277) (LSLED15V20W277)

20W power supply with 15V DC output for non-dimmable applications
