Hakea LED HA1

HA1
LS201LED
A compact and versatile wall grazer
Configure this product

Product Overview

TheLS201LED Hakea is a compact, fixed position, direct or indirect accent used for grazing walls or other accent illumination tasks. The luminaire is constructed from either copper or powder-coated aluminIum, providing a variety of aesthetic options. This luminaire is ideal for use in modern architectural designs, and features the Lumascape d5 driver technology for advanced dimming and control options.

THIS LUMINAIRE IS ONLY AVAILABLE IN NORTH AMERICA

Specifications

Features

Lumen Output 403lm Power Consumption 6W Control Protocol PWM (0-10V, DMX) IP Rating IP65 Compliance ETL - USA & Canada Colour Options BIM Blue Cool White Warm White Download Datasheet

Product Configurator

Customise Hakea LED HA1 below

Power Consumption

Required

6W

6W

Light Source

Required

3,000 K (80 CRI)

3,000 K (80 CRI)

Warm White

4,000 K (80 CRI)

4,000 K (80 CRI)

Cool White

470nm

470nm

Blue

Beam Angles

Published angles may vary slightly to photo-metric data. Please refer to IES files where relevant.

Required

Narrow

Narrow

14º

Narrow Medium

Narrow Medium

25 ̊

Medium

Medium

30 ̊

Wide

Wide

40º

Input Voltage

Required

12-15V 60Hz or 12-24V DC

12-15V 60Hz or 12-24V DC

PWM Dimmable Driver

Finish

Required

Black

Black

Black powdercoat on Stainless Steel

Anodic Silver

Anodic Silver

Anodic silver powdercoat on Stainless Steel

Polished Copper

Polished Copper

Accessories

Power Supplies / Transformers

20W 15V Power Supply

20W 15V Power Supply

20W power supply with 15V DC output for non-dimmable applications

120W Power Supply

120W Power Supply

24V high durability polymeric enclosed power supply for wet locations

240W Power Supply

240W Power Supply

30V high durability polymeric enclosed power supply for wet locations

320W Power Supply

320W Power Supply

24V high durability polymeric enclosed power supply for harsh environments
